Cable Management Systems
Lightweight aluminium profile cable trays for installations where weight matters, in h=70 and h=100 mm edge heights, with a full range of bends, tees, crossings, vertical bends, covers and separators in the same system.
Every model, stock code, dimension and weight below is drawn directly from the Gersan Cable Support catalogue.
| Model | Stock Code | Width (mm) | Height (mm) | Thickness (mm) | Material / Finish | Action |
|---|---|---|---|---|---|---|
| GNM-20 ALAluminium Profile Cable Trays | 230802002AL1 | 200 | 70 | 2 | Aluminium | |
| GNM-30 ALAluminium Profile Cable Trays | 230803002AL1 | 300 | 70 | 2 | Aluminium | |
| GNM-40 ALAluminium Profile Cable Trays | 230804002AL1 | 400 | 70 | 2 | Aluminium | |
| GNM-50 ALAluminium Profile Cable Trays | 230805002AL1 | 500 | 70 | 2 | Aluminium | |
| GNM-60 ALAluminium Profile Cable Trays | 230806002AL1 | 600 | 70 | 2 | Aluminium | |
| GNM-B20 ALAluminium Profile Cable Trays | 231002002AL1 | 200 | 70 | 2 | Aluminium | |
| GNM-B30 ALAluminium Profile Cable Trays | 231003002AL1 | 300 | 70 | 2 | Aluminium | |
| GNM-B40 ALAluminium Profile Cable Trays | 231004002AL1 | 400 | 70 | 2 | Aluminium | |
| GNM-B50 ALAluminium Profile Cable Trays | 231005002AL1 | 500 | 70 | 2 | Aluminium | |
| GNM-B60 ALAluminium Profile Cable Trays | 231006002AL1 | 600 | 70 | 2 | Aluminium | |
| GNMD-20 AL90° Flat Bend Element (6063 Aluminium Alloy) | 164802002AL1 | 200 | 70 | 2 | Aluminium | |
| GNMD-30 AL90° Flat Bend Element (6063 Aluminium Alloy) | 164803002AL1 | 300 | 70 | 2 | Aluminium | |
| GNMD-40 AL90° Flat Bend Element (6063 Aluminium Alloy) | 164804002AL1 | 400 | 70 | 2 | Aluminium | |
| GNMD-50 AL90° Flat Bend Element (6063 Aluminium Alloy) | 164805002AL1 | 500 | 70 | 2 | Aluminium | |
| GNMD-60 AL90° Flat Bend Element (6063 Aluminium Alloy) | 164806002AL1 | 600 | 70 | 2 | Aluminium | |
| GNMD-B20 AL90° Flat Bend Element (6063 Aluminium Alloy) | 1648B2002AL1 | 200 | 70 | 2 | Aluminium | |
| GNMD-B30 AL90° Flat Bend Element (6063 Aluminium Alloy) | 1648B3002AL1 | 300 | 70 | 2 | Aluminium | |
| GNMD-B40 AL90° Flat Bend Element (6063 Aluminium Alloy) | 1648B4002AL1 | 400 | 70 | 2 | Aluminium | |
| GNMD-B50 AL90° Flat Bend Element (6063 Aluminium Alloy) | 1648B5002AL1 | 500 | 70 | 2 | Aluminium | |
| GNMD-B60 AL90° Flat Bend Element (6063 Aluminium Alloy) | 1648B6002AL1 | 600 | 70 | 2 | Aluminium | |
| GNMT-20 ALTees "T" Element (6063 Aluminium Alloy) | 172902002AL1 | 200 | 70 | 2 | Aluminium | |
| GNMT-30 ALTees "T" Element (6063 Aluminium Alloy) | 172903002AL1 | 300 | 70 | 2 | Aluminium | |
| GNMT-40 ALTees "T" Element (6063 Aluminium Alloy) | 172904002AL1 | 400 | 70 | 2 | Aluminium | |
| GNMT-50 ALTees "T" Element (6063 Aluminium Alloy) | 172905002AL1 | 500 | 70 | 2 | Aluminium | |
| GNMT-60 ALTees "T" Element (6063 Aluminium Alloy) | 172906002AL1 | 600 | 70 | 2 | Aluminium | |
| GNMT-B20 ALTees "T" Element (6063 Aluminium Alloy) | 1729B2002AL1 | 200 | 70 | 2 | Aluminium | |
| GNMT-B30 ALTees "T" Element (6063 Aluminium Alloy) | 1729B3002AL1 | 300 | 70 | 2 | Aluminium | |
| GNMT-B40 ALTees "T" Element (6063 Aluminium Alloy) | 1729B4002AL1 | 400 | 70 | 2 | Aluminium | |
| GNMT-B50 ALTees "T" Element (6063 Aluminium Alloy) | 1729B5002AL1 | 500 | 70 | 2 | Aluminium | |
| GNMT-B60 ALTees "T" Element (6063 Aluminium Alloy) | 1729B6002AL1 | 600 | 70 | 2 | Aluminium | |
| GNMDB-20 ALCrossing Element (6063 Aluminium Alloy) | 182602002ALI | 200 | 70 | 2 | Aluminium | |
| GNMDB-30 ALCrossing Element (6063 Aluminium Alloy) | 182603002ALI | 300 | 70 | 2 | Aluminium | |
| GNMDB-40 ALCrossing Element (6063 Aluminium Alloy) | 182604002ALI | 400 | 70 | 2 | Aluminium | |
| GNMDB-50 ALCrossing Element (6063 Aluminium Alloy) | 182605002ALI | 500 | 70 | 2 | Aluminium | |
| GNMDB-60 ALCrossing Element (6063 Aluminium Alloy) | 182606002ALI | 600 | 70 | 2 | Aluminium | |
| GNMDB-B20 ALCrossing Element (6063 Aluminium Alloy) | 1826B2002AL1 | 200 | 70 | 2 | Aluminium | |
| GNMDB-B30 ALCrossing Element (6063 Aluminium Alloy) | 1826B3002AL1 | 300 | 70 | 2 | Aluminium | |
| GNMDB-B40 ALCrossing Element (6063 Aluminium Alloy) | 1826B4002AL1 | 400 | 70 | 2 | Aluminium | |
| GNMDB-B50 ALCrossing Element (6063 Aluminium Alloy) | 1826B5002AL1 | 500 | 70 | 2 | Aluminium | |
| GNMDB-B60 ALCrossing Element (6063 Aluminium Alloy) | 1826B6002AL1 | 600 | 70 | 2 | Aluminium | |
| GNMIC-20 ALInside Vertical Element (6063 Aluminium Alloy) | 193302002AL1 | 200 | 70 | 2 | Aluminium | |
| GNMIC-30 ALInside Vertical Element (6063 Aluminium Alloy) | 193303002AL1 | 300 | 70 | 2 | Aluminium | |
| GNMIC-40 ALInside Vertical Element (6063 Aluminium Alloy) | 193304002AL1 | 400 | 70 | 2 | Aluminium | |
| GNMIC-50 ALInside Vertical Element (6063 Aluminium Alloy) | 193305002AL1 | 500 | 70 | 2 | Aluminium | |
| GNMIC-60 ALInside Vertical Element (6063 Aluminium Alloy) | 193306002AL1 | 600 | 70 | 2 | Aluminium | |
| GNMIC-B20 ALInside Vertical Element (6063 Aluminium Alloy) | 1933B2002AL1 | 200 | 70 | 2 | Aluminium | |
| GNMIC-B30 ALInside Vertical Element (6063 Aluminium Alloy) | 1933B3002AL1 | 300 | 70 | 2 | Aluminium | |
| GNMIC-B40 ALInside Vertical Element (6063 Aluminium Alloy) | 1933B4002AL1 | 400 | 70 | 2 | Aluminium | |
| GNMIC-B50 ALInside Vertical Element (6063 Aluminium Alloy) | 1933B5002AL1 | 500 | 70 | 2 | Aluminium | |
| GNMIC-B60 ALInside Vertical Element (6063 Aluminium Alloy) | 1933B6002AL1 | 600 | 70 | 2 | Aluminium |
